一、用途Use
本產品適用于交流50Hz,額定電壓0.6/1KV的線路中，供輸配電能之用。
The cable is used as power distribution and transim
二、使用特性Using property
1)電纜導體的額定溫度為70℃。
2)短路時（持續時間不超過5S）電纜導體的溫度不超過160℃。
3)敷設電纜時的環境溫度不低于0℃，彎曲半徑應不小于電纜外徑的10倍。
1)The long-time working temperature of cable should not be highter than 70℃.
2)When core is in short-circuit(max 5s)the temperature should not exceed 160℃.
3)While installation the ambient temperature should not be lower than 0℃,and the bending radius should not be less than 10 times of outer dismeter of cable.
三、型號、名稱和使用范圍（見表1）Model,name and application (see table 1)
| 型號Model | 名 稱 Name | 適用范圍 Main application |
|
VV VLV |
聚氯乙烯絕緣聚氯乙烯護套電力電纜 PVC insulated PVC sheathed power cable |
敷設在室內、隧道及管道中，電纜不能承受壓力和機械外力作用。 for laying indoors,inducts and kin tunels,but unable to bear pulling force and pressure. |
|
VV22 VLV22 |
聚氯乙烯絕緣鋼帶鎧裝聚氯乙烯護套電力電纜 PVC insulated steel tape amoured PVC sheathed power cable |
敷設在室內、隧道及直埋土壤中，電纜能承受壓力和其他外力作用。 for laying indoors,in tunels and direct in ground,able to bear pulling force and pressure. |
|
VV32 VLV32 |
聚氯乙烯絕緣細鋼絲鎧裝聚氯乙烯護套電力電纜 PVC insulated fine steel wire armoured PVC sheathed power cable |
敷設在室內、隧道及直埋土壤中，電纜能承受壓力和其他外力作用。 for laying down wells and under water,able to bear certain pulling force. |
|
VV42 VLV42 |
聚氯乙烯絕緣粗鋼絲鎧裝聚氯乙烯護套電力電纜 PVC insulated steel winre armoured PVC sheathed power cable |
敷設在室內、礦井中，水中，電纜能承受相當?shù)睦Α?/p> for laying down wells and under watedr,able to bear certain pulling force. |
|
ZR-VV ZR-VLV |
聚氯乙烯絕緣聚氯乙烯護套阻燃電力電纜 PVC insulated PVC sheathed flame retardant power cable |
敷設在豎井，水下等垂直場合，能承受相當?shù)妮S向拉力。 for laying indoors,inducts and kin tunels,but unable to bear pulling force and pressure. |
|
ZR-VV22 ZR-VLV22 |
聚氯乙烯絕緣鋼帶鎧裝聚氯乙烯護套阻燃電力電纜 PVC insulated steel tape armoured PVC sheathed flame retardant power cable |
敷設在室內、隧道及直埋土壤中，電纜能承受壓力和其他外力作用 for laying indoors,in tunels and direct in ground,able to bear pulling force and pressure. |
|
ZR-VV32 ZR-VLV32 |
聚氯乙烯絕緣細鋼絲鎧裝聚氯乙烯護套阻燃電力電纜 pvc insulated fine steel wire armoured PVC sheathed flame retar-dant power cable |
敷設在室內、礦井中，水中，電纜能承受相當?shù)睦Α?/p> for laying down wells and under water,able to bear certain axis pulling force and pressure. |
|
ZR-VV42 ZR-VLV42 |
聚氯乙烯絕緣粗鋼絲鎧裝聚氯乙烯護套阻燃電力電纜 PVC insulated steel wire armoured PVC sheathed flame retar-dant power cable |
敷設在豎井，水下燈垂直場合，能承受相當?shù)妮S向拉力。 for laying down wells and under watedr,able to bear certain |
